Butt to Butt Label Unwinding and Auto Rewinding

Simplified Automation: Focused on Reliability and Reproducibility The FL’s architecture emphasizes simplicity, repeatability, and global serviceability. Featuring servo-driven active feeding and magnetic powder secondary tension systems, the unwinder delivers stable tension ideal for a range of materials—from composite laminates to heat-sensitive films . Its built-in roll handling system lifts and places rolls up to 500kg, eliminating manual crane use during roll change events. Cutting and splicing are handled by a pulley-type device that ensures clean, burr-free edges, while the fixed-angle tape spool dispenses adhesive on both webs, joining them at a 10° butt splice. The head-to-head adhesive connection is ideal for die-cut and resin-coated webs, avoiding issues like crushing or puffing seen with overlap splices. Web edge guidance is achieved through a combination of EPC and laser sensors, helping to align during splicing and minimize prepress setup time. Maintenance is streamlined v…
