DCDC Converter

Model NO. BADC10050 Main Circuit Type Voltage Voltage of Power Supply High Voltage Variable-Frequency Drive Link of Transformation AC-DC-AC Variable-Frequency Drive Function Simple Type DC bus Voltage range 200 ~ 420Vdc DC bus Rated voltage 370Vdc DC bus Max Current 17 Amax (at 200~290 Vdc, ≤12 A) Battery-side Voltage range 30~100Vdc Battery-side Rated voltage 60Vdc Power rating 5kW Transport Package Ceramic Specification 22x9x44cm Trademark LM Origin China Production Capacity 10000PCS/Month Packaging & Delivery Package Size 22.00cm * 9.00cm * 44.00cm Package Gross Weight 7.000kg Product Description Product Name: BADC10050 Bidirectional DCDC Module DC bus side Voltage range: 200 ~ 420Vdc Rated voltage: 370Vdc Max Current: 17 Amax (at 200~290 Vdc, ≤12 A) Battery-side Voltage range: 30~100Vdc Rated voltage: 60Vdc Max Current: 105Amax Power rating: 5kW Steady-current accuracy: ≤±5% Current ripple: <5% Voltage ripple: < 2% Softstart time: 3s ≤ t ≤8s Standby power consump…
