High column flat uniaxial tracking photovoltaic support

High column flat uniaxial tracking photovoltaic support is a design that increases the height of the rotation axis of the support (usually column height ≥2 meters) and combines horizontal uniaxial tracking technology to improve the power generation efficiency of the photovoltaic system. Its core feature is high-level installation and horizontal single-axis rotation, which not only retains the low-cost advantage of horizontal single-axis but also improves rear power generation, reduces obstructions and meets the requirements of special scenarios by increasing the height from the ground. The following is the detailed analysis: 1. Core structure and working principle   High column design: The height of the support column is significantly higher than that of the conventional flat single-axis (usually 2 to 5 meters), and the support structure needs to enhance its wind and torsion resistance performance.One Axis Solar Tracker Solar   Horizontal single-axis rotation: Photovoltaic modules…
