10kV Dry-type Cast-coil Series Reactor

LEABE 10 kV Dry-Type Cast-Coil Series Reactor (CKSC Series) Product Overview The LEABE 10 kV Dry-Type Cast-Coil Series Reactor (CKSC Series) is a premium Harmonic Filter Reactor engineered to enhance power quality in medium-voltage networks. Designed for series connection with capacitor banks, this Industrial Reactor effectively suppresses harmonic resonance, limits inrush currents, and stabilizes voltage waveforms. Utilizing advanced vacuum casting technology and precision-engineered silicon steel cores, LEABE delivers a robust, maintenance-free solution that optimizes system reliability and energy efficiency for global industrial and commercial applications. Technical Specifications Rated Voltage: 3kV, 6kV, 10kV, 20kV, 35kV (Standard 10kV Class) Rated Capacity: 3 kvar to 2000 kvar System Frequency: 50Hz / 60Hz Reactance Rate (p): 1%, 4.5%, 5%, 6%, 12% (Customizable) Insulation Class: F (155°C) Cooling Method: ANAN (Air Natural) Winding Material: High-purity copper wire/foil C…
