500mm Swing Gearbox CNC Lathe

Product Name: 500 Swing Gearbox CNC Lathe   Model: YNMZ-6150B   Standard Configuration   • Swing over bed: Φ500   • Bed length: 500mm ~ 5000mm   • 3-speed gearbox structure: High speed 350~1600rpm, Medium speed 150~700rpm, Low speed 42~200rpm   • Guideway width: 400mm; 1-V & 1-flat guideway structure   • Spindle bore: Φ80   • Φ250 3-jaw manual chuck, manual tailstock, A2-8 spindle, 4-station electric turret, integral bed base / split bed base   • CNC System: GSK, FANUC, SIEMENS, SYNTEC   • 7.5KW variable frequency spindle motor   Optional Configuration   • Swing over bed: Φ560, Φ630, Φ660   • Guideway type: Double V guideway, linear guideway, middle-mounted lead screw, 470mm width guideway   • Spindle bore: Φ105   • Hydraulic chuck, hydraulic tailstock   • 6-station electric turret, 8-station servo turret
