Precision Strip Shear Welder for Industrial Use

Shear Welder is a key auxiliary equipment in continuous production lines such as ERW tube mills and cold roll forming lines. It is mainly used to shear and square the tail of one steel coil and the head of the next coil, then butt-weld them together, enabling continuous strip feeding and preventing line stoppage during coil change.   Main Functions:   · Shearing: Vertically cuts the tail of the finished coil and the head of the new coil square, ensuring a flat, burr-free cut · Centering: Precisely aligns the two squared strip ends to ensure welding quality · Welding: Welds the aligned strip ends together to form a continuous strip   Core Components:   · Gantry Shear Unit: High-rigidity gantry frame structure, hydraulically driven, vertical cutting for shear accuracy · Centering Mechanism: Horizontal and vertical adjustment devices to precisely align the two strip ends · Welding Unit: Typically TIG or plasma welding for weld strength and flatness · Clamping Unit: Secures the steel st…
