XZG1500 Large High Pressure Auto Filter Press

  XZG1500 Hydraulic Clamping Auto Plate Pulling Diaphragm Filter Press The XZG1500 is a hydraulic clamping auto pressure holding auto plate pulling diaphragm filter press. It works as a Diaphragm Filter Press that belongs to the large high pressure fully automatic category. This machine is bigger than the XZG1250 with higher capacity and stronger squeezing force. It is built for large scale deep dewatering applications including mine tailings, sand washing slurry, municipal sludge, and chemical sludge. The plate size is 1500 by 1500 millimeters. The membrane plate thickness is 85 millimeters and the standard plate thickness is 78 millimeters. The filtering area ranges from 200 to 600 square meters depending on the plate count you choose. The maximum filtration pressure is 1.2 MPa. The maximum squeeze pressure goes up to 1.6 MPa which is 16 bar. The filtration process on this Sludge Dewatering Equipment follows two stages. First is positive pressure filtration for solid liquid separati…
