XZG2000 Ultra High Capacity Diaphragm Filter Press

XZG2000 Hydraulic Clamping Auto Plate Pulling Diaphragm Filter Press The XZG2000 is a hydraulic clamping auto pressure holding auto plate pulling diaphragm filter press. It works as a Diaphragm Filter Press with plate size of 2000 by 2000 millimeters. The membrane plate thickness is 90 millimeters and the standard plate thickness is 83 millimeters. Each single plate gives more filtering area and chamber volume than smaller models. With the same number of plates, this unit handles much higher throughput than the XZG1600, XZG1500, or XZG1250. This machine is built for ultra large factories, big mining operations, and centralized sludge treatment centers. One unit alone can meet large scale production needs. This saves you from buying multiple smaller presses and reduces floor space. The XZG2000 follows a clear eight step workflow. First the hydraulic system presses all plates together. Second the high pressure feed sends slurry into the chambers. Third the diaphragm plates perform the h…
