ROTARY DIECUTTER MACHINE

This is the automatic high speed roatry die-cutting machine for making corrugated carton.   Main Specification: (optional Jumbo size such as 1600x3200mm, 1800x4000mm, etc) Size (mm) 1400*2000 1400*2400 Max. feeding speed(pcs/min)   160 160 Common speed(pcs/min)  90-120 90-120 Max.die cutting size(mm) 1380×2000 1380×2000 Min. die cutting size(mm) 400×600 400×600 Applicant Cardboard thickness(mm) 2-11 2-11 Die cutting accuracy(mm) ±1 ±1 Main motor power (kw) 7.5 7.5   Description: Feeding Unit:  1) Lead edge feeder with Yaskawa servo control system, electronic CAM segmentation technology to replace the complex mechanical CAM segmentation device work, fundamentally solve the mechanical CAM can not eliminate the air gap, so as to ensure the accuracy of positioning and paper feeding accuracy. Servo control technology is characterized by high precision, high speed and good stability. 2) Equipped with ge…
